DL40DAU-A
DL40DAU-A
Electric ATV designed for adventure, recreation, and complex terrain. Combines off-road capability with versatility and zero emissions.
| Motor type | Permanent magnet synchronous motor | Battery System | Lithium,4.6kWh Nominal |
| Transmission | H/M/L/N/R; Shaft | Front /Rear Brakes | Disc |
| Max.Speed | 65km/h | Drive system | 2WD |
| Rear suspension | Integral bridge suspension | Front suspension | MacPherson independent suspension |
PARAMETERS
-
ENGINE & DRIVETRAIN
-
Drive System
2WD
-
Max.Speed
65km/h
-
Motor Type
Permanent Magnet Synchronous Motor
-
Horse power
11HP
-
Transmission
H/M/L/N/R; Shaft
-
Battery System
Lithium,4.6kWh Nominal
-
-
DIMENSIONS
-
Curb Weight
551 lbs.（250kg）
-
Ground Clearance
7.87 in.（20cm）
-
Overall Vehicle Size (L x W x H)
78×41.7×47.3 in.（198×106×120cm）
-
Payload Capacity
187 lbs.（85kg）
-
Person Capacity
1
-
Seat Height
31.5 in.（80cm）
-
Wheelbase
46 in.（117cm）
-
Estimated Range
50-60km
-
-
BRAKES
-
Front/Rear Brakes
Disc
-
Parking Brake
Mechanical Handle
-
-
ADDITIONAL SPECIFICATIONS
-
Instrumentation
Digital Instrument
-
Lighting
Dual front headlights, turn signals, combination taillights
-
-
TIRES / WHEELS
-
Front Tires
24*8-12
-
Rear Tires
24*10-12
-
Quantity
20GP:10pcs，40HQ:30pcs
-
-
SUSPENSION
-
Front Suspension
McPherson independent suspension
-
Rear Suspension
Integral bridge suspension
-
SELLING POINT
Disc brake system
Professional off-road tires
Full hydraulic spring damping system
Pure Electric Power System
Stable chassis design
CAN communication system
APPLICATION
DL40DU-A inclined sinusoidal Road
DL40DU-A Small sine path
DL40DU-A Large sine path
DL40DU-A Belgian Road
