DL250AU

ENGINE & DRIVETRAIN

• Active Descent Control

  Not Applicable

• Cooling

  liquid

• Cylinders Displacement

  229cc

• Drive System

  2WD

• Max.Speed

  60km/h

• Engine Type

  4-stroke single cylinder

• Fuel System

  Carburetor

• Horse power

  16HP

• Transmission

  6-speed manual；shaft

DIMENSIONS

• Curb Weight

  551 lbs.（250kg）

• Fuel Capacity

  11.8L

• Ground Clearance

  6.7 in.（17cm）

• Overall Vehicle Size (L x W x H)

  76.8×46.5×52.4 in.(195×118×133cm)

• Payload Capacity

  187 lbs.(85kg)

• Person Capacity

  1

• Seat Height

  32.28 in.（82cm）

• Wheelbase

  45.28 in.（115cm）

BRAKES

• Front/Rear Brakes

  Front disc brake/rear drum brake

• Parking Brake

  Lockable handle handbrake

ADDITIONAL SPECIFICATIONS

• Instrumentation

  All digital instrument panel, including vehicle speed, mileage, speed, gear indication, fuel level, high and low beam, and turn signal indication.

• Lighting

  35 watt high and low beam LED dual headlights, 4 10 watt incandescent bulbs for turn signals, etc. The 5W/21W dual filament taillights include brake and position lights.

TIRES / WHEELS

• Front Tires

  22*8-10

• Rear Tires

  22*10-10

• Quantity

  20GP：10pcs，40HQ：33pcs

SUSPENSION

• Front Suspension

  McPherson independent suspension

• Rear Suspension

  Integral bridge suspension
