DL320AU
| Cooling | liquid | Drive System | 4WD |
| Horsepower | 23HP | Engine Type | 4-stroke single cylinder |
| Fuel System | Elctronic fuel injection | Transmission | Automatic H/L/N/R；Shaft |
| Rear Suspension | Independent suspension | Front Suspension | Wishbone suspension |
| Lighting | 35 watt high and low beam LED dual headlights, 4 10 watt incandescent bulbs for turn signals, etc. The 5W/21W dual filament taillights include brake and position lights. | Instrumentation | All digital instrument panel, including vehicle speed, mileage, speed, gear indication, fuel level, high and low beam, and turn signal indication. |
PARAMETERS
-
ENGINE & DRIVETRAIN
-
Cylinders Displacement
287CC
-
Drive System
4WD
-
Max.Speed
80km/h
-
Engine Type
4-stroke single cylinder
-
Fuel System
Electronic fuel injection
-
Horse power
23HP
-
Transmission
Automatic H/L/N/R; Shaft
-
-
DIMENSIONS
-
Curb Weight
717lbs.（325kg）
-
Fuel Capacity
14L
-
Ground Clearance
11.8 in.（30cm）
-
Overall Vehicle Size (L x W x H)
80.7×45.7×47.3 in.（205×116×120cm）
-
Payload Capacity
331·lbs.（150kg）
-
Person Capacity
2
-
Seat Height
35.43 in.（90cm）
-
Wheelbase
55.12 in.（140cm）
-
-
BRAKES
-
ADDITIONAL SPECIFICATIONS
-
TIRES / WHEELS
-
Front Tires
25*8-12
-
Rear Tires
25*10-10
-
Quantity
20GP：10pcs，40HQ：33pcs
-
-
SUSPENSION
-
Front Suspension
Wishbone suspension
-
Rear Suspension
Independent suspension
-
